Size and Weight
Height: 177.4 mm
Width: 81.5 mm
Depth: 12.75 mm
Weight: 332 grams

Charging and battery
5280mAh Battery
Rated capacity: 2640mAh 7.74V
Rated energy: 20.434Wh
Built-in lithium-ion polymer battery
USB Type-C port
Supports 120W super fast charging
Supports 50W wireless charging
Supports wireless reverse charging

Rugged
Splash, Water and Dust Resistant
Rated IP68 maximum depth of 2.0 metres up to 30 minutes under IEC standard 60529
Rated IP69K under IEC standard 60529
MIL-STD-810H Certification

*Armor 23 Ultra is splash, water, and dust resistant and was tested under controlled laboratory conditions with a rating of IP68 under IEC standard 60529 maximum depth of 2.0 meters up to 30 minutes. Charger and accessories are not water-resistant. Splash, water and dust resistance are not permanent and might decrease as a result of normal wear. Do not attempt to charge a wet Armor 23 Ultra.
Liquid damage not covered under warranty.

Processor
MediaTek Dimensity 8020 with 5G
CPU: MediaTek MT6891
CPU architecture: 4*Cortex-A78+4*Cortex-A55, 6nm process
CPU frequency: Octa Core, up to 2.6GHz
GPU: Arm Mali-G77

Storage and RAM
12GB+512GB
RAM: 12GB large memory, LPDDR4X
Flash storage: 512GB phone storage, UFS 3.1
microSD memory card Up to 2TB

Display
6.78‑inch diagonal
Punch-hole Display
All-screen LCD Multi-Touch display with IPS technology
20.5 : 9, 1080 x 2460 FHD+
396 ppi
Refresh rate: 120 Hz
Touch sampling rate: 240Hz
Corning® Gorilla® Glass Victus®
Fingerprint-resistant oleophobic coating

Rear Camera
50MP+50MP+64MP+3.2x Optical Zoom
50MP Main Camera, 1/1.31 Ultra-large Lens
Samsung S5KGN1 CMOS sensor, 1.2μm, 7 piece lens, FOV 84.7°, ƒ/1.65 large aperture, EIS
50MP Ultra Wide-angle Camera
Hi5022Q CMOS sensor, FOV 117.3°, ƒ/2.2 large aperture, EIS
64MP Night Vision Camera
OV64B1B CMOS sensor, ƒ/1.79 large aperture
3.2X Optical Zoom Telephoto Lens
3.2X-30X focal length, ZOOM EIS
Photo resolution: up to 6144x8160 pixels
Video resolution: up to 4K
Dual LED Flash
Rear camera photography features
Normal mode, Night Vision Mode, Film Mode, 50MP Mode, Night Mode, Gif, Portrait, Pro Mode, Panorama, Slow Motion, Time Lapse, Macro, Intelligent Scanning
HDR, Filters, AI scene detection, Location info, Brand watermark, Camera mute, Touch shooting, Self timer, Grid line, Volume key feature, Anti flicker, Long Press
Rear camera video features
4K recording 30fps
1080P recording 30fps
720P recording 30fps
480P recording 30fps

Front Camera
50MP selfie camera
1.0µm, 5 piece lens, FOV 80.4°, ƒ/2.25 large aperture
Front camera photography features
Normal mode, Film, 50MP, Gif, Portrait
Filters, Location info, Brand watermark, Mirror, Camera mute, Touch shooting, Self timer, Grid line, Volume key feature, Anti flicker
Front camera video features
1080P recording 30fps
720P recording 30fps
480P recording 30fps

Underwater Photography
Supports to take photos video recording
Supports to start/end operation underwater
Supports to quickly switch shooting modes underwater

Unlock Options
Supports Fingerprint Unlock
Side-Mounted Fingerprint, Integrate power key and fingerprint sensor together
Capacitive Touch Sensor
Response speed: Up to 0.1s
Supports the enrollment of 5 sets of fingerprint
Supports Face Unlock

Network
Dual Nano SIM either card can be set as the primary card
Supports 5G/4G/3G/2G
Supports VoLTE HD calling

Connectivity
WLAN
Supports protocols: 802.11 a/b/g/n/ac/ax
Supports 2.4G/5G, WiFi 6
Bluetooth
Supports Bluetooth 5.1

Navigation and positioning
Supports multiple positioning systems
GPS L1+L5 Dual Band
GLONASS
Galileo
BEIDOU
QZSS
NavlC GPS
Supports Digital Compass

NFC
Supports Google Pay
Supports Transit, Loyalty Cards, Gift Cards and Plane tickets

Operating System
Android 13
Pure Android System
No ads

Sensors
Infrared sensor, NFC, Proximity sensor, Light sensor, Gravity sensor, Acceleration sensor, Geomagnetic sensor, Gyro sensor, Coulomb counter, Pedometer, Air pressure sensor

Ports
Type-C, USB 3.1 Gen 1
Device: USB 3.1 Gen 1, Host: USB 2.0

Card slot
Three3, Nano SIM + Nano SIM + microSD

Notification Light
Support, tri-color light, red/green/blue
Supports charging prompt

In the box
Armor 23 Ultra
AC Power Charger Adapter
Data Cable
Protective FilmPre-installed
Tempered Glass Screen Protector
SIM Needle
Lanyard
Multi-language User Manual
Multi Function Instruction Card
Bullitt Satellite Messenger User Guide
Charging Instruction card
Safety Prompt card
Accesories Ecosystem Brochure
Service Center Instructions
Warranty card
