2.3va 230vac 2x12v 2x95ma transformer encapsulated
HAHN
2.3va 230vac 2x12v 2x95ma transformer encapsulated
HAHN
2.3va 230vac 2x12v 2x95ma transformer encapsulated
from
€5.50
to
- 18%
- 18%
€4.50
Only 1 left!
Pay in 3, 6 or 9 installments for orders over €50 using
[{"value":"1","url":"/on/demandware.store/Sites-Jinius-Site/en_GB/Product-OfferAvailability?p11Quantity=1&pid=6263130&productId=048d3723-6694-481d-a8d7-880d3dc10ed7&quantity=1"}]
–+
[{"value":"1","url":"/on/demandware.store/Sites-Jinius-Site/en_GB/Product-OfferAvailability?p11Quantity=1&pid=6263130&productId=048d3723-6694-481d-a8d7-880d3dc10ed7&quantity=1"}]
–+
8
Points earned
Low stock
Description
Item No.
048d3723-6694-481d-a8d7-880d3dc10ed7
- Manufacturer: HAHN
- Type of transformer: encapsulated
- Power: 2.3VA
- Primary voltage: 230V AC
- Secondary voltage 1: 12V
- Secondary voltage 2: 12V
- Secondary winding current 1: 95mA
- Secondary winding current 2: 95mA
- Mounting: PCB
- Conform to the norm: PN-EN 61558-2-6:2000, UL 5085-1, UL 5085-3
- Thermal class: Ta40/F
- Weight: 81g
- Body dimensions: 32.5 x 27.5 x 23.8mm
Additional information
- Gross weight: 82.7 g
