Product Features

· Wireless HDMI signal transmission up to 50 m (unobstructed view)
· Supports resolutions up to 1920x1080p
· Wireless channel: IEEE 802.11ac, 5 GHz, 2T2R
· HDMI version: 1.4
· HDCP version: 1.3
· AES 128 bit encryption
· WPA2 protocol
· Authentication protocol: WPA2 (WPAS-PSK / WPA2-Enterprise)
· Supports Windows, macOS, iOS, iPadOS, Android
· Connections per unit: 1x HDMI plug, 1x Micro-USB jack
· Power supply: HDMI jack (0.5A required) or via Micro-USB (DC 5V/0.5A)
· Connection button with LED status display
· Audio: Stereo, 16 bits / 48 KHz
· ABS housing
· Power consumption: approx. 2.5W
· Operating temperature: 0-40 °C
· Dimensions (1 unit): L 8.3 x W 3.2 x H 1.3 cm
· Weight (1 unit): 27 g
· Color: Black
· The transmission distance with a restricted visual range cannot be determined Generally and depends on the specific circumstances where installed.
· Walls, glass etc. shorten the signal range or cause signal losses.

Special Features

· Wireless HDMI signal transmission up to 50 m (with unobstructed view)
· Supports up to 16x transmitters (sources) + 1x receiver (output device)
· Extend this set with up to 16 transmitter units (DS-55320)
· Switch to the desired transmitter quickly and easily at the press of a button in order to reproduce your content
· Share from a tablet/smartphone using the screen sync (iOS, iPadOS/Android) of your mobile device
· Supports Windows, macOS, iOS, iPadOS, Android
· Supports resolutions up to Full HD (1080p / 60 Hz)
· Easy operation and handling thanks to Plug & Play - Just plug in and get started
· Transmitter can be supplied with power via your devices HDMI connection (> 500 mA required). To have a safe and stable operation, we recommend to use always the Micro USB cables for power supply of TX and RX.
