Asustor lockerstor 8 as6508t 8-bay tower nas intel atom c3538 8GB dual 10GBe dual 2.5GBe m.2 diskless black

Product image: Asustor lockerstor 8 as6508t 8-bay tower nas intel atom c3538 8GB dual 10GBe dual 2.5GBe m.2 diskless black-null
Product image: Asustor lockerstor 8 as6508t 8-bay tower nas intel atom c3538 8GB dual 10GBe dual 2.5GBe m.2 diskless black-null
Product image: Asustor lockerstor 8 as6508t 8-bay tower nas intel atom c3538 8GB dual 10GBe dual 2.5GBe m.2 diskless black-null
ASUS
🔥Selling fast!

Asustor lockerstor 8 as6508t 8-bay tower nas intel atom c3538 8GB dual 10GBe dual 2.5GBe m.2 diskless black

€1,638.17
or
Pay in 3, 6 or 9 interest-free monthly installments and 0 service fees with Fleksy image
Select Color: Black
In stock
–+
–+
3276
Points earned
You can earn Antamivi points every time you make a payment using your Bank of Cyprus cards.
The number of Antamivi points and the corresponding amount of money displayed are indicative and may vary from time to time. Want to know more? Check out our FAQs here.
If you are an eligible member of the Bank of Cyprus loyalty scheme Pronomia, you will receive additional Antamivi points based on your assigned tier.
From: Singular Computers Systems LTD
Buy more from this shop
Delivery options
Delivery to your door
FREE shipping on orders over €85.00 from Singular Computers Systems LTD
Est. delivery: 03 Aug - 05 Aug
Free

Description

Item No. c4b24c55-b516-43fc-bcd0-08aaf4b1cb60
ASUSTOR Lockerstor 8 AS6508T 8-Bay NAS 8 BaysDual 10GBEIntel Atom C3538Dual M.2 Cache The ASUSTOR Lockerstor 8 (model AS6508T, part number 90-AS6508T00-MD30) is an eight-bay tower NAS built for high-throughput small-business and prosumer storage. It combines a quad-core Intel Atom C3538 processor, 8GB of DDR4 memory and, uniquely in its class, both dual 10GBE and dual 2.5GBE networking — up to 20GBps of aggregated bandwidth — plus two M.2 slots for SSD caching. Running ASUSTOR’s ADM operating s

Attributes

Hdd General Characteristics

  • Disk Type: USB3.0 | Ethernet | SATA | iSCSI | M.2

Details

ASUSTOR Lockerstor 8 AS6508T 8-Bay NAS

8 BaysDual 10GBEIntel Atom C3538Dual M.2 Cache

The ASUSTOR Lockerstor 8 (model AS6508T, part number 90-AS6508T00-MD30) is an eight-bay tower NAS built for high-throughput small-business and prosumer storage. It combines a quad-core Intel Atom C3538 processor, 8GB of DDR4 memory and, uniquely in its class, both dual 10GBE and dual 2.5GBE networking — up to 20GBps of aggregated bandwidth — plus two M.2 slots for SSD caching. Running ASUSTOR’s ADM operating system, it is ideal for demanding backup, media and virtualization workloads. Typically in stock with fast delivery across Cyprus.

Before you buy — sold diskless
This NAS ships without drives. Install up to eight 3.5-inch or 2.5-inch SATA HDDs/SSDs (NAS-grade recommended) plus optional M.2 SSDs (2280/2260/2242) for read/write caching. The two M.2 slots are for SSD cache acceleration rather than primary storage volumes.

Best For

✓High-bandwidth 10GBE workgroups and studios
✓Large media libraries and video editing storage
✓Backup and archiving for growing businesses
✓Virtualization storage over fast networking
✓SSD-cached workloads needing high IOPS
✓Users scaling toward 8 bays and beyond

Key Features


Dual 10GBE + dual 2.5GBE
Two 10GBASE-T and two 2.5GBE ports deliver up to 20GBps under link aggregation, giving multiple users fast simultaneous access — a standout feature at this bay count.

Eight-bay capacity
Eight hot-swap 3.5in/2.5in SATA bays provide substantial raw capacity, expandable further with the AS6004U expansion unit for large archives.

Quad-core Atom C3538
The server-class Intel Atom C3538 with AES-NI encryption handles multi-user file serving, backup and virtualization reliably around the clock.

M.2 SSD caching
Two M.2 slots (PCIe NVMe or SATA) add read or read/write SSD cache for up to a 60% performance boost on frequently accessed data.

Technical Specifications

Identification
Part Number 90-AS6508T00-MD30
EAN / GTIN 4710474831210
MPN AS6508T
Processor & Memory
CPU Intel Atom C3538 — quad-core x86, 2.1GHz, AES-NI
Memory 8GB DDR4 SO-DIMM, expandable to 64GB (2x 32GB), 2 slots
Storage
Drive Bays 8x 3.5in / 2.5in SATA 6GB/s, hot-swappable
M.2 Slots 2x M.2 (2280/2260/2242, PCIe NVMe or SATA) — SSD cache
RAID Single, JBOD, 0, 1, 5, 6, 10, plus hot-spare
iSCSI Supported — up to 256 targets / 256 LUNs, MPIO
Connectivity
Network 2x 10GBE (10GBASE-T) + 2x 2.5GBE — up to 20GBps aggregated
USB 2x USB 3.2 Gen1 (5GBps) Type-A
HDMI None
System & Power
Operating System ADM (ASUSTOR Data Master)
Power Supply 250W internal PSU
Dimensions (HxWxD) 215.5 x 293 x 230 mm
Weight 6.2 kg
Colour Black
Warranty 3 years

Frequently Asked Questions

Does the AS6508T come with drives?
No, it is supplied diskless. Fit up to eight 3.5-inch or 2.5-inch SATA drives plus optional M.2 SSDs for caching. NAS-grade drives are recommended.
What networking does it have?
It has two 10GBE (10GBASE-T) ports and two 2.5GBE ports. Under link aggregation these can combine for up to 20GBps, ideal for high-bandwidth multi-user access.
Can the memory be upgraded?
Yes. It ships with 8GB DDR4 across two SO-DIMM slots and supports up to 64GB (2x 32GB) for heavier multitasking and virtualization.
What is the difference between the AS6508T and AS6510T?
They are the same platform — same CPU, RAM, 10GBE/2.5GBE networking and M.2 slots. The AS6510T simply adds two more bays for ten drives instead of eight.
Singular Expert Insight
The Lockerstor 8 stands out for bundling dual 10GBE and dual 2.5GBE at an eight-bay price point, so you get serious network throughput without buying add-in cards. If you need ten bays, the AS6510T is the same machine with two extra slots; if 10GBE is overkill, the Celeron-based Nimbustor line (2.5GBE, with HDMI) costs less. Fill it with 24/7-rated NAS hard drives and add M.2 SSDs for caching to get the most from the fast networking.

Buyer's Guide

Buy it if
You want eight bays with built-in dual 10GBE and dual 2.5GBE for fast, multi-user storage and backup.
Skip it if
You need onboard HDMI ouTPUt for local playback, or an all-flash M.2 design — look at the Nimbustor or Flashstor lines.
Also consider
The 10-bay ASUSTOR AS6510T for more capacity, or the AS6004U expansion unit to grow this NAS later.
