Description

Item No. 69c50df3-42a5-4e35-ba13-20fa57cfb9ee
Cisco Catalyst 9136I Wi-Fi 6E Access Point Wi-Fi 6E Tri-Band8x8, up to 10.2GBps2x 5G MultigigabitUPOE / 802.3bt The Cisco Catalyst 9136I (part number C9136I-E, EMEA regulatory domain) is Cisco's flagship Wi-Fi 6E access point for the most demanding enterprise networks. It runs three radios — 2.4 GHz 4x4, 5 GHz 8x8 and 6 GHz 4x4 — for up to 10.2GBps aggregate, adding the clean 6 GHz band for high-density performance. Dual 5 Gigabit multigigabit uplinks provide redundant, high-bandwidth backhau

Details

Cisco Catalyst 9136I Wi-Fi 6E Access Point

Wi-Fi 6E Tri-Band8x8, up to 10.2GBps2x 5G MultigigabitUPOE / 802.3bt

The Cisco Catalyst 9136I (part number C9136I-E, EMEA regulatory domain) is Cisco's flagship Wi-Fi 6E access point for the most demanding enterprise networks. It runs three radios — 2.4 GHz 4x4, 5 GHz 8x8 and 6 GHz 4x4 — for up to 10.2GBps aggregate, adding the clean 6 GHz band for high-density performance. Dual 5 Gigabit multigigabit uplinks provide redundant, high-bandwidth backhaul, and it is powered by Cisco UPOE (802.3bt) with BLE 5 for IoT, managed by a Cisco Catalyst 9800 controller. Typically in stock with fast delivery across Cyprus.

Deployment note
For full performance, power the 9136I with Cisco UPOE / 802.3bt (up to ~47.3 W); 802.3at PoE+ runs with reduced functionality. Use a multigigabit (2.5/5G) switch on the uplinks to avoid a bottleneck. It requires Cisco management: a Catalyst 9800 Series controller or a Catalyst 9k switch with Embedded Wireless Controller, running IOS XE 17.7.1 or later, plus appropriate licensing. This is the “-E” EMEA regulatory variant; 6 GHz benefits need Wi-Fi 6E client devices.

Best For

✓The highest-density Wi-Fi 6E in offices, campuses and venues
✓Maximising 5 GHz capacity with 8x8 MU-MIMO
✓Adding the clean 6 GHz band for capable client devices
✓Redundant, multi-gig backhaul with dual 5G uplinks
✓Cisco-managed estates on Catalyst 9800 / IOS XE
✓IoT and location services via built-in BLE 5

Key Features


Tri-Band Wi-Fi 6E, up to 10.2GBps
Three radios — 2.4 GHz 4x4, 5 GHz 8x8 and 6 GHz 4x4 — deliver up to 10.2GBps aggregate and add the clean 6 GHz band for high-density Wi-Fi 6E.

8x8 MU-MIMO & OFDMA
Eight spatial streams on 5 GHz plus OFDMA — dividing airtime among many clients — sustain performance in the busiest environments.

Dual 5G Multigigabit Uplinks
Two 100M/1G/2.5G/5G multigigabit ports provide redundant, high-bandwidth backhaul so the wired side is not the bottleneck.

UPOE Power & Cisco Management
Powered by Cisco UPOE (802.3bt), with BLE 5 for IoT, and managed centrally through a Catalyst 9800 controller or Embedded Wireless Controller on IOS XE.

Technical Specifications

Identification
Part Number C9136I-E (EMEA domain)
EAN / GTIN 0889728441490
MPN C9136I-E
Brand Cisco
Wireless
Wi-Fi Standard Wi-Fi 6E (802.11ax), tri-band 2.4 / 5 / 6 GHz
Radios 2.4 GHz 4x4 + 5 GHz 8x8 + 6 GHz 4x4 (tri-radio; quad-radio via software)
Aggregate Rate PHY data rates up to 10.2GBps
MIMO 8x8 MU-MIMO on 5 GHz, OFDMA
Antennas Internal antennas
IoT Bluetooth Low Energy (BLE) 5
Connectivity
Uplinks 2 x 100M/1G/2.5G/5G Multigigabit (RJ-45), redundant
Power & Management
Power Cisco UPOE / 802.3bt (up to ~47.3 W); 802.3at PoE+ reduced
Management Cisco Catalyst 9800 controller or Embedded WLC, IOS XE 17.7.1+
General
Deployment Indoor access point
Colour White
Warranty 1-Year Warranty (Singular)

Frequently Asked Questions

What does Wi-Fi 6E add over Wi-Fi 6?
Wi-Fi 6E extends Wi-Fi 6 into the 6 GHz band for a large block of clean spectrum with less interference and lower latency. The 9136I combines this with 8x8 on 5 GHz for up to 10.2GBps. Clients must support Wi-Fi 6E to use 6 GHz.
What power and switch does the 9136I need?
For full performance use Cisco UPOE / 802.3bt (up to ~47.3 W) and connect the dual multigigabit uplinks to a 2.5/5G switch. 802.3at PoE+ runs the AP with reduced functionality.
How is the 9136I managed?
Through a Cisco Catalyst 9800 Series controller or a Catalyst 9k switch with Embedded Wireless Controller, running IOS XE 17.7.1 or later, with appropriate licensing.
What does the “-E” in C9136I-E mean?
“-E” is the EMEA regulatory domain, which sets the permitted channels and transmit power for Europe, the Middle East and Africa.
Singular Expert Insight
The 9136I is Cisco's flagship Wi-Fi 6E AP: 8x8 on 5 GHz, tri-band with 6 GHz and dual 5G uplinks for the highest-density Cisco deployments. If you are ready for the next standard, the Wi-Fi 7 CW9176I/9178I add higher aggregate and 10G uplinks; if you only need mid-density, a lower-tier AP is more economical. It needs UPOE and a Catalyst 9800 stack, so plan power and management. Pair it with a multi-gig UPOE switch from our switches range, and compare our full access points range across Wi-Fi 6E and Wi-Fi 7.

Buyer's Guide

Buy it if
You run a Cisco Catalyst 9800 estate and need flagship Wi-Fi 6E — 8x8, 6 GHz and dual 5G uplinks — for the highest-density sites.
Skip it if
You want the newest Wi-Fi 7 (choose CW9176I/9178I), only need mid-density, or cannot provide UPOE and a Catalyst 9800 controller.
Also consider
The Cisco Wireless 9176I/9178I for Wi-Fi 7, a lower-tier Wi-Fi 6E AP for mid-density, and a multi-gig UPOE switch to power and backhaul the unit.
