Zebra ds3678-sr ds3678-sr0f003vzww ultra-rugged cordless 1d 2d barcode scanner bluetooth fips vibration industrial green

€766.30
or
Pay in 3, 6 or 9 interest-free monthly installments and 0 service fees with Fleksy image
Select Color: Green
In stock
–+
–+
1532
Points earned
You can earn Antamivi points every time you make a payment using your Bank of Cyprus cards.
The number of Antamivi points and the corresponding amount of money displayed are indicative and may vary from time to time. Want to know more? Check out our FAQs here.
If you are an eligible member of the Bank of Cyprus loyalty scheme Pronomia, you will receive additional Antamivi points based on your assigned tier.
From: Singular Computers Systems LTD
Buy more from this shop
Delivery options
Pick-up points / Lockers
Est. delivery: 31 Jul - 03 Aug
Free
Delivery to your door
FREE shipping on orders over €85.00 from Singular Computers Systems LTD
Est. delivery: 03 Aug - 05 Aug
Free

Description

Item No. c65252c6-bc82-4bc4-abec-8294563f73bd
Zebra DS3678-SR — Ultra-Rugged Cordless 1D/2D Imager (FIPS, Vibration) IP67 + IP65 SealingSurvives 2.4 m DropsBluetooth 4.0 + Wi-Fi Friendly100,000+ Scans per Charge The Zebra DS3678-SR (part number DS3678-SR0F003VZWW, EAN 0783555128312) is an ultra-rugged cordless 1D/2D area imager for warehouses, manufacturing floors and cold storage, capturing any barcode — printed, damaged, under shrink-wrap or on a screen — from near contact to nearly 1.5 m away. This FIPS-enabled configuration in industri

Attributes

Details

Zebra DS3678-SR — Ultra-Rugged Cordless 1D/2D Imager (FIPS, Vibration)

IP67 + IP65 SealingSurvives 2.4 m DropsBluetooth 4.0 + Wi-Fi Friendly100,000+ Scans per Charge

The Zebra DS3678-SR (part number DS3678-SR0F003VZWW, EAN 0783555128312) is an ultra-rugged cordless 1D/2D area imager for warehouses, manufacturing floors and cold storage, capturing any barcode — printed, damaged, under shrink-wrap or on a screen — from near contact to nearly 1.5 m away. This FIPS-enabled configuration in industrial green adds a vibration motor for unmistakable good-read feedback in loud environments. It is Zebra’s most indestructible scanner class: dual IP65/IP67 sealing, 2.4 m drops to concrete and 5,000-tumble endurance. This is the scanner-only SKU — the communication/charging cradle, cables and power supply are sold separately. Typically in stock with fast delivery across Cyprus.

Compatibility & Usage Note
Scanner only: to communicate and charge you need a Zebra cradle (e.g. STB3678 presentation or FLB3678 forklift cradle) plus the appropriate USB/RS-232/Ethernet cable and power supply — all sold separately. The PowerPrecision+ battery is supplied with the scanner. Bluetooth 4.0 (Class 1, ~100 m) also pairs directly with PCs, tablets and Zebra mobile computers via HID/SPP.

Best For

✓ Warehouse receiving, picking & shipping
✓ Manufacturing floors — WIP and quality tracking
✓ Cold storage and freezer operations
✓ Yard and dock work — waterproof to IP67
✓ Loud environments — vibration good-read feedback
✓ Government/defence sites requiring FIPS security

Key Features


Practically Indestructible
Survives 2.4 m / 8 ft drops to concrete, 5,000 tumbles, and carries dual IP65/IP67 sealing — sprayed with jetting water or fully submersed, it keeps scanning, even in freezer cold.

Captures Any Code, Fast
The advanced imager reads 1D/2D codes printed, on screens, under shrink-wrap, dirty or damaged — near contact to ~1.5 m — and Multi-Code captures up to 20 barcodes with one trigger pull.

Cordless Done Right
Bluetooth 4.0 LE with Zebra’s Wi-Fi Friendly Mode keeps your WLAN clean, while the PowerPrecision+ battery delivers 100,000+ scans per charge with full health telemetry.

FIPS + Vibration Feedback
This configuration is FIPS-certified for secure government and healthcare deployments, and the vibration motor confirms good reads where beeps cannot be heard.

Technical Specifications

Identification
Part Number DS3678-SR0F003VZWW
EAN / GTIN 0783555128312
MPN DS3678-SR0F003VZWW
Series Zebra 3600 Ultra-Rugged Series (DS3678-SR cordless, standard range)
Configuration FIPS — Federal cryptographic security standard + vibration motor
Kit Contents
In the Box Scanner with PowerPrecision+ battery
Sold Separately Communication/charging cradle (STB3678/FLB3678), USB/RS-232/Ethernet cables, power supply
Reading Performance
Scanner Type Omnidirectional 2D area imager (1D + 2D)
Working Range Near contact to ~1.5 m (13 mil UPC ~ 8.6 in nominal far point on dense codes; large codes further)
Field of View 42° H x 28° V
Read Angles Skew ±60° + Pitch ±60° + Roll 0–360°
Min Print Contrast 15%
Feedback Vibration motor + red/green LEDs + adjustable beeper
Multi-Code Captures and formats up to 20 barcodes in one trigger pull
Digimarc Supports Digimarc digital watermark barcodes
Decoding Capability
1D Code 39, Code 128, Code 93, Codabar/NW7, Code 11, MSI Plessey, UPC/EAN, Interleaved 2 of 5, Korean 3 of 5, GS1 DataBar, Base 32
2D QR + Micro QR, Data Matrix, PDF417 + Micro PDF417, Aztec, MaxiCode, Composite, TLC-39, Han Xin, DotCode, Postal codes
IUID Parses and separates IUID fields for defence applications
Connectivity
Wireless Bluetooth 4.0 Low Energy — Wi-Fi Friendly Mode avoids WLAN interference
Host Interfaces (via cradle) USB + RS-232 + Keyboard Wedge + Industrial Ethernet (Network Connect for Automation)
Battery
Battery PowerPrecision+ Li-Ion — 100,000+ scans per charge, health telemetry (charge cycles, State of Health)
Environmental
Drop Resistance Withstands multiple 2.4 m / 8 ft drops to concrete
Tumble Testing 5,000 tumbles (real-world drop simulation)
Sealing IP67 — dustproof and waterproof (submersion) + IP65 jetting spray; cradle IP65
Environment Extreme temperature rated — freezer to heat
Physical
Dimensions 18.5 x 7.6 x 14.2 cm (H x W x D)
Weight ~407 g
Colour Industrial Green
Software
DataCapture DNA 123Scan, Scanner Management Service (SMS), SDKs, Remote management

Frequently Asked Questions

What do I need to use the Zebra DS3678-SR0F003VZWW?
A communication/charging cradle (STB3678 presentation or FLB3678 forklift), the matching host cable (USB, RS-232 or Ethernet) and a power supply — all sold separately from this scanner-only SKU. Alternatively pair it directly to a PC, tablet or Zebra mobile computer over Bluetooth.
What does FIPS mean on this model?
FIPS is the US Federal cryptographic security standard: Bluetooth traffic between scanner and cradle is encrypted to certified levels, required in many government, defence and healthcare deployments. Performance is identical to non-FIPS models.
Can the DS3678-SR read barcodes on screens and damaged labels?
Yes. The advanced imager captures 1D and 2D codes displayed on screens or printed on labels — even dirty, damaged, poorly printed or under shrink-wrap — from near contact to nearly 1.5 m away.
What is the difference between the DS3678-SR and the DS3678-ER?
Range: the SR (standard range) covers near contact to ~1.5 m — ideal for receiving, picking and production lines. The ER (extended range) reads from 7.6 cm out to 21.4 m for high-bay warehouse racking. Ruggedness and features are identical.
Singular Expert Insight
The 3600 Series is what you buy when scanners keep dying on the floor: 2.4 m drops, IP67 submersion and freezer-rated electronics put the DS3678 in a different league from retail imagers like the DS2208. This FIPS + vibration configuration targets secure sites and loud floors specifically — if you need neither, the standard DS3678-SR0F003VZWW-class sibling without FIPS costs less. Remember to budget for the cradle and cables, or pair directly via Bluetooth to Zebra mobile computers. For high-bay racking, step up to the DS3678-ER extended-range variant.

Buyer’s Guide

Buy it if
Scanners in your operation face drops, water, dust or freezer temperatures + you need cordless 1D/2D capture with all-shift battery life + FIPS security or vibration feedback is a requirement + Multi-Code and Digimarc future-proofing appeal.
Skip it if
You scan at a retail counter (the DS2208/DS2278 cost far less) + you need to read racking 3 m and higher (choose the DS3678-ER) + you don’t want to buy the cradle, cables and PSU separately (look for a full kit part number).
Also consider
Zebra DS3678-ER — same body, 7.6 cm to 21.4 m range for high bays. Zebra DS3608-SR — corded sibling, no cradle needed. Zebra DS2278 — light-duty cordless for retail budgets.
