System

• Main Processor: Embedded Processor
• Operation System: Embedded LINUX OS
• Button Type : Mechanical
• Interoperability : ONVIF
• Network Protocol : SIP; P2P; IPv4; DNS; RTSP; RTP; TCP; UDP

Basic

• Camera : 1/2.8'' 2MP CMOS high definition, low illumination/WDR/color/IR
• Field of View : Horizontal: 125°; vertical: 71°; diagonal: 142°
• WDR : 120dB
• Noise Reduction : 3D noise reduction
• Video Compression : H.264 , H.265
• Video Resolution : Main stream: WVGA, 720P, D1 Sub stream: CIF, WVGA, QVGA, 1080P, D1
• Video Frame Rate : PAL:25 fps NTSC:30 fps
• Video Bit Rate : 256 Kbps–8 Mbps
• Light Compensation : Auto IR
• Day/Night : ICR auto switch
• Audio Compression : G.711Mu; G.711u; PCM
• Audio Input : 1
• Audio Output : Built-in speaker
• Audio Mode : Two-way audio
• Audio Enhancement : Echo suppression and cancellation/digital noise reduction
• Audio Bit Rate : 16KHz, 16Bit

Function

• Communication Mode : Full digital
• Unlock Mode : Card/app/indoor monitor unlock
• Card Type : IC card
• Motion Detection : Video motion detection
• Auto Snapshot : Auto snapshot can only be enabled on indoor monitors
• Leave Videos : Yes (Insert an SD card into the indoor monitor)
• Wi-Fi : Yes
• Wireless Standard : IEEE802.11b/802.11g/802.11n
• Wireless Frequency Range : 2.4GHz
• Storage : Supports Micro SD card (up to 256GB)
• Web Configuration : Yes

Performance

• Card Reading Distance : 0 cm–4.3 cm
• Casing : PC+Acrylic

Capacity

• Card : 10,000

Port

• RS-485 : 1
• Electric Lock : 1
• Alarm Input : 1
• Alarm Output : 1
• Power Output : 1
• Exit Button : 1
• Door Status Detection : 1
• Lock Control : 1, normally closed by default
• Network : 1 * 10M/100M network port

Alarm

• Tamper : Yes

General

• Color : Black plate & silvery frames
• Power Supply : 12V DC 1A / Standard PoE
• Installation : Surface mount
• Certifications : CE/FCC/UL
• Accessory : Brackets and alarm ribbon cable
• Dimensions : 150 mm × 100 mm ×24.8 mm
• Protection Grade : IP65 (Silicone sealant is needed, see the quick start guide.)
• Operating Temperature : -30°C to +60°C (-22°F to +140°F)
• Operating Humidity : 10%RH–90%RH (non-condensing)
• Operating Environment : Outdoor
• Operating Altitude : Beneath 3000 m (9842.51 ft)
• Power Consumption : Standby≤1W, working≤7W
• Gross Weight : 510 g
