Gigabyte b860 ds3h Wi-Fi 6e atx lga1851 ddr5 motherboard

Product image: Gigabyte b860 ds3h Wi-Fi 6e atx lga1851 ddr5 motherboard-null
Product image: Gigabyte b860 ds3h Wi-Fi 6e atx lga1851 ddr5 motherboard-null
Product image: Gigabyte b860 ds3h Wi-Fi 6e atx lga1851 ddr5 motherboard-null
Product image: Gigabyte b860 ds3h Wi-Fi 6e atx lga1851 ddr5 motherboard-null
GIGABYTE
🔥Πωλείται γρήγορα!

Gigabyte b860 ds3h Wi-Fi 6e atx lga1851 ddr5 motherboard

από € 214.95 σε - 10% - 10% € 193.46
ή
Πλήρωσε σε 3, 6 ή 9 άτοκες δόσεις με 0 χρεώσεις υπηρεσίας χρησιμοποιώντας το Fleksy image
Επιλογή Χρώμα: Black
–+
–+
386
Points earned
Μπορείτε να κερδίζετε βαθμούς Ανταμοιβή κάθε φορά που πραγματοποιείτε μια πληρωμή με τις κάρτες της Τράπεζας Κύπρου.
Ο αριθμός των βαθμών Ανταμοιβή και το αντίστοιχο ποσό χρημάτων που εμφανίζονται είναι ενδεικτικά και μπορεί να διαφέρουν κατά καιρούς. Θέλετε να μάθετε περισσότερα; Ελέγξτε τις Συχνές Ερωτήσεις μας εδώ.
Εάν είστε δικαιούχο μέλος του σχεδίου επιβράβευσης Pronomia της Τράπεζας Κύπρου, θα λαμβάνετε επιπλέον βαθμούς Ανταμοιβή ανάλογα με την βαθμίδα σας.
Από Singular Computers Systems LTD
Σε απόθεμα
Επιλογές μεταφορικών
Σημεία / Θυρίδες παραλαβής
Εκτ. παράδοση: 21 Μαϊ - 22 Μαϊ
Δωρεάν
Παράδοση στην πόρτα σου
Δωρεάν αποστολή για παραγγελίες άνω των € 85.00 από το Singular Computers Systems LTD
Εκτ. παράδοση: 21 Μαϊ - 25 Μαϊ
Δωρεάν

Περιγραφή

Αριθμός προϊόντος: 248aad31-0da0-498d-9245-e499ba441cbc
Singular Selected Gigabyte B860 DS3H WiFi 6E A clean ATX foundation for Intel Core Ultra Series 2 builds — PCIe 5.0 graphics, PCIe 5.0 M.2 storage, fast DDR5 and onboard Wi-Fi 6E in one accessible board. PCIe 5.0 x16DDR5 9066 O.C.PCIe 5.0 M.2Wi-Fi 6E + 2.5GBE The Gigabyte B860 DS3H WiFi 6E is a full-size ATX motherboard built for the new Intel Core Ultra (Series 2) processors on the LGA1851 socket. It pairs the Intel B860 chipset with an 8+1+2 phase Hybrid VRM, four DDR5 DIMM slots (up to 256GB

Χαρακτηριστικά

Χαρακτηριστικά Μητρικής Κάρτας

  • Θύρα Επεξεργαστή: Socket 1851

Λεπτομέρειες

Singular Selected

Gigabyte B860 DS3H WiFi 6E

A clean ATX foundation forIntel Core Ultra Series 2 builds — PCIe 5.0 graphics, PCIe 5.0 M.2 storage, fast DDR5 and onboard Wi-Fi 6E in one accessible board.
PCIe 5.0 x16DDR5 9066 O.C.PCIe 5.0 M.2Wi-Fi 6E + 2.5GBE

The Gigabyte B860 DS3H WiFi 6E is a full-size ATX motherboard built for the newIntel Core Ultra (Series 2) processors on the LGA1851 socket. It pairs the Intel B860 chipset with an 8+1+2 phase Hybrid VRM, four DDR5 DIMM slots (up to 256GB at 9066 MT/s O.C.), a reinforced PCIe 5.0 x16 graphics slot and two M.2 slots — one PCIe 5.0 and one PCIe 4.0. Onboard Wi-Fi 6E with WIFI EZ-Plug, Realtek 2.5GBE LAN, USB 3.2 Gen 2x2 Type-C and a 5GB/s front USB-C header round out the connectivity for everyday gaming and creator builds.

Compatibility Note: LGA1851 socket only — supportsIntel Core Ultra Series 2 processors. Earlier 12th/13th/14th Gen LGA1700 CPUs are not compatible. Requires DDR5 memory; DDR4 modules cannot be used.
Best For
✓ NewIntel Core Ultra Series 2 builds
✓ Mid-range gaming PCs with PCIe 5.0 GPUs
✓ Builders who want PCIe 5.0 NVMe storage
✓ Wireless setups needing onboard Wi-Fi 6E

Key Features


Intel Core Ultra Series 2 Ready
A fresh LGA1851 platform with an 8+1+2 phase Hybrid VRM, designed to feed Intel's latest Core Ultra processors with stable, efficient power for gaming and content workloads.

PCIe 5.0 Graphics + PCIe 5.0 M.2
A reinforced PCIe 5.0 x16 slot powers next-gen GPUs, while a dedicated PCIe 5.0 M.2 slot pushes NVMe storage to its peak — both wired straight to the CPU.

DDR5 up to 9066 MT/s (O.C.)
Four DDR5 DIMM slots support up to 256GB of dual-channel memory with XMP 3.0 profiles and Gigabyte's D5 Bionic Corsa tuning for high-frequency kits.

Wi-Fi 6E + 2.5GBE Networking
Onboard Wi-Fi 6E (2.4 / 5 / 6 GHz) with WIFI EZ-Plug for easy antenna setup, plus a Realtek 2.5GBE LAN port for fast, stable wired connections.

Technical Specifications

Part Number B860 DS3H WIFI6E
EAN 4719331867515
Form Factor ATX
CPU Socket Intel LGA1851 (Intel Core Ultra Series 2)
Chipset Intel B860 Express
VRM 8+1+2 Phase Hybrid Digital VRM
Memory 4x DDR5 DIMM, up to 256GB, dual channel, up to 9066 MT/s (O.C.), XMP 3.0
Expansion Slots 1x PCIe 5.0 x16 (CPU, with PCIe UD Slot + EZ-Latch) + 4x PCIe 4.0 x1 (chipset)
M.2 Storage 1x PCIe 5.0 M.2 + 1x PCIe 4.0 M.2 (with M.2 Thermal Guard, EZ-Latch Plus)
SATA 4x SATA 6GB/s
Wireless Wi-Fi 6E 802.11ax (2.4 / 5 / 6 GHz) + Bluetooth · WIFI EZ-Plug
LAN 2.5GBE
USB (Rear) 1x USB 3.2 Gen 2x2 Type-C + 1x USB 3.2 Gen 2 + 4x USB 2.0
USB (Front) Front USB-C 5GB/s header + additional USB headers
Display OuTPUts 1x DisplayPort + 1x HDMI (CPU integrated graphics required)
Audio 8-Channel HD Audio with High-End Audio Capacitors
RGB Headers 3x Addressable RGB Gen2 + 1x RGB LED strip header
DIY Features Q-Flash Plus, PCIe EZ-Latch, M.2 EZ-Latch Plus, WIFI EZ-Plug, Debug LEDs
PCB 6-Layer PCB, Mid-Loss

Frequently Asked Questions

Which CPUs are supported?
Intel Core Ultra Series 2 processors on the new LGA1851 socket. Older 12th/13th/14th Gen Core CPUs (LGA1700) are not compatible. Always check Gigabyte's official CPU support list and required BIOS version.
How many M.2 SSDs can I install?
Two M.2 NVMe SSDs — one PCIe 5.0 slot and one PCIe 4.0 slot, both with M.2 Thermal Guard. There are also 4x SATA 6GB/s ports for additional drives.
Does it support DDR4 memory?
No — this board is DDR5 only. It supports up to 256GB across four DIMM slots, with speeds up to 9066 MT/s (O.C.) using XMP 3.0 profiles.
Do I need a separate Wi-Fi card?
No. Wi-Fi 6E and Bluetooth are built in, with the WIFI EZ-Plug design making antenna installation straightforward. A 2.5GBE wired LAN port is also included.
Singular Expert Insight
Choose this board if you're building a freshIntel Core Ultra Series 2 PC and want a clean ATX layout with PCIe 5.0 graphics, PCIe 5.0 M.2 storage and Wi-Fi 6E at an accessible price. If you need three M.2 slots or richer rear I/O, step up to the B860 Eagle WiFi 6E or B860 Gaming X WiFi 6E. For Micro-ATX cases, consider the B860M DS3H WiFi 6E instead.

Buyer's Guide

Buy it if
You're building an ATX gaming or creator PC with a newIntel Core Ultra Series 2 CPU and want PCIe 5.0 graphics, PCIe 5.0 NVMe and onboard Wi-Fi 6E.
Skip it if
You own an LGA1700 CPU or DDR4 memory, need three or more M.2 slots, or want a Z890 board for unlocked CPU overclocking.
Also consider
Gigabyte B860 Gaming X WiFi 6E (richer I/O, 3x M.2) or B860M DS3H WiFi 6E (Micro-ATX, smaller cases).
