Gigabyte b760 gaming x Wi-Fi 6e Gen5 atx lga1700 ddr5 motherboard

Name: Gigabyte b760 gaming x Wi-Fi 6e Gen5 atx lga1700 ddr5 motherboard
Brand: GIGABYTE
SKU: 9ed14620-f699-4dc9-a81e-b61aa346fe55
Price: 190.00 EUR
Availability: InStock

€ 211.11 - 10% € 190.00

Πλήρωσε σε 3, 6 ή 9 άτοκες δόσεις με 0 χρεώσεις υπηρεσίας χρησιμοποιώντας το

Επιλογή Χρώμα: Black

Ποσότητα

–+

Από Singular Computers Systems LTD

Σε απόθεμα

Σημεία / Θυρίδες παραλαβής

Εκτ. παράδοση: 29 Μαϊ - 02 Ιουν

Δωρεάν

Παράδοση στην πόρτα σου

Δωρεάν αποστολή για παραγγελίες άνω των € 85.00 από το Singular Computers Systems LTD

Εκτ. παράδοση: 29 Μαϊ - 03 Ιουν

Δωρεάν

Περιγραφή

Αριθμός προϊόντος: 9ed14620-f699-4dc9-a81e-b61aa346fe55

Singular Selected Gigabyte B760 Gaming X WiFi 6E Gen5 A future-ready ATX motherboard for 12th/13th/14th Gen Intel builds — PCIe 5.0 graphics slot, DDR5, three M.2 drives and Intel Wi-Fi 6E in one clean board. PCIe 5.0 x16DDR5 up to 256GB3x M.2 PCIe 4.0Wi-Fi 6E + 2.5GBE The Gigabyte B760 Gaming X WiFi 6E Gen5 is a full-size ATX motherboard built for Intel 12th, 13th and 14th Gen Core, Pentium Gold and Celeron processors on the LGA1700 socket. It pairs the Intel B760 chipset with four DDR5 DIMM s

Χαρακτηριστικά

Χαρακτηριστικά Μητρικής Κάρτας

Θύρα Επεξεργαστή: Socket 1700

Λεπτομέρειες

Singular Selected

Gigabyte B760 Gaming X WiFi 6E Gen5

A future-ready ATX motherboard for 12th/13th/14th Gen Intel builds — PCIe 5.0 graphics slot, DDR5, three M.2 drives and Intel Wi-Fi 6E in one clean board.

PCIe 5.0 x16DDR5 up to 256GB3x M.2 PCIe 4.0Wi-Fi 6E + 2.5GBE

The Gigabyte B760 Gaming X WiFi 6E Gen5 is a full-size ATX motherboard built for Intel 12th, 13th and 14th Gen Core, Pentium Gold and Celeron processors on the LGA1700 socket. It pairs the Intel B760 chipset with four DDR5 DIMM slots (up to 256GB at 7600 MT/s O.C.), a PCIe 5.0 x16 slot for next-generation graphics cards, three M.2 PCIe 4.0 x4 slots for fast NVMe storage, Intel Wi-Fi 6E AX210 with Bluetooth 5.3, and Realtek 2.5GBE wired networking — a balanced foundation for gaming, content creation and high-performance workstations.

Compatibility Note: LGA1700 socket only (Intel 12th/13th/14th Gen). Confirm CPU compatibility on Gigabyte's official CPU support list before purchase. Requires DDR5 memory — DDR4 modules are not compatible.

Best For

✓ Mid-range gaming builds with PCIe 5.0 GPUs

✓ Content creators needing fast NVMe storage

✓ Workstation upgrades on existing LGA1700 CPUs

✓ Builders wanting Wi-Fi 6E without an add-in card

Key Features

PCIe 5.0 Graphics Slot

A reinforced x16 slot wired directly to the CPU runs at PCIe 5.0 speeds — twice the bandwidth of PCIe 4.0 — ready for the latest GPUs and PCIe 5.0 NVMe drives.

DDR5 Memory, Up to 256GB

Four DDR5 DIMM slots support up to 256GB of dual-channel memory and speeds up to 7600 MT/s (O.C.) with XMP, giving headroom for heavy multitasking and creative workloads.

Triple M.2 + 4 SATA Storage

Three M.2 slots (all PCIe 4.0 x4) plus four SATA 6GB/s ports with RAID 0/1/5/10 support let you mix fast NVMe drives with bulk storage in one build.

Wi-Fi 6E + 2.5GBE Networking

Onboard Intel Wi-Fi 6E AX210 with Bluetooth 5.3 covers 2.4 / 5 / 6 GHz bands, while a Realtek 2.5GBE LAN port keeps wired connections fast and stable.

Technical Specifications

Part Number	B760 G X WF6E Gen5
EAN	4719331871673
Form Factor	ATX, 30.5 x 24.4 cm
CPU Socket	Intel LGA1700 (12th / 13th / 14th Gen Core, Pentium Gold, Celeron)
Chipset	Intel B760 Express
Memory	4x DDR5 DIMM, up to 256GB, dual channel, up to 7600 MT/s (O.C.), XMP support
Expansion Slots	1x PCIe 5.0 x16 (CPU) + 2x PCIe 3.0 x1 (chipset)
Storage	3x M.2 PCIe 4.0 x4 (1 from CPU, 2 from chipset) + 4x SATA 6GB/s, RAID 0/1/5/10
Wireless	Intel Wi-Fi 6E AX210 (2.4 / 5 / 6 GHz, 11ax 160MHz) + Bluetooth 5.3
LAN	Realtek 2.5GBE (2.5 / 1GBps / 100 Mbps)
USB (Rear)	1x USB 3.2 Gen 2 Type-A + 1x USB 3.2 Gen 1 Type-C + 1x USB 3.2 Gen 1 Type-A + 5x USB 2.0
Internal USB	USB 3.2 Gen 2 Type-C header + USB 3.2 Gen 1 header + 2x USB 2.0 headers
Display OuTPUts	1x DisplayPort 1.2 (4096x2304@60Hz) + 1x HDMI 2.1 (4096x2160@60Hz)
Audio	Realtek HD Audio, 7.1-channel, S/PDIF Out
RGB Headers	3x Addressable RGB Gen2 + 1x RGB LED strip header
BIOS	256 Mbit AMI UEFI, Q-Flash, Q-Flash Plus, Smart Backup
OS Support	Windows 11 64-bit, Windows 10 64-bit

Frequently Asked Questions

Which CPUs are supported?

Intel 12th, 13th and 14th Gen Core, Pentium Gold and Celeron processors on the LGA1700 socket. Always check Gigabyte's official CPU support list for your exact model and required BIOS version.

Does it support DDR4 memory?

No — this board is DDR5 only. It supports up to 256GB across four DIMM slots, with speeds up to 7600 MT/s (O.C.) via XMP.

Is the PCIe 5.0 slot useful for current GPUs?

Most current GPUs use PCIe 4.0 and run at full speed in this slot. The PCIe 5.0 slot future-proofs the build for next-generation graphics cards and PCIe 5.0 NVMe SSDs as adoption grows.

How many M.2 SSDs can I install?

Up to three M.2 NVMe SSDs (all PCIe 4.0 x4, type 22110/2280) — one wired directly to the CPU and two via the chipset. Four SATA 6GB/s ports add room for additional drives.

Singular Expert Insight

Choose this board if you want a full-size ATX layout with PCIe 5.0 graphics, three M.2 slots and onboard Wi-Fi 6E for an Intel 12/13/14th Gen build. If you don't need PCIe 5.0 or onboard Wi-Fi, the cheaper B760 Gaming X DDR4 (DDR4 memory) or B760M Gaming X (Micro-ATX) trims cost without losing core platform features.

Buyer's Guide

Buy it if

You're building an ATX gaming or workstation PC on Intel 12/13/14th Gen, want PCIe 5.0 GPU readiness, DDR5 memory and three M.2 slots in one board.

Skip it if

You already own DDR4 memory, need a Micro-ATX or Mini-ITX build, or want a Z790/Z890 board for unlocked CPU overclocking.

Also consider

Gigabyte B760 Gaming X DDR4 (reuse DDR4 memory) or B760M Gaming X WiFi 6E (Micro-ATX, smaller cases).
