Gigabyte h810m k micro-atx motherboard lga 1851 intel h810 ddr5 pcie 4.0 x16 m.2 HDMI displayport gbe black

Product image: Gigabyte h810m k micro-atx motherboard lga 1851 intel h810 ddr5 pcie 4.0 x16 m.2 HDMI displayport gbe black-null
Product image: Gigabyte h810m k micro-atx motherboard lga 1851 intel h810 ddr5 pcie 4.0 x16 m.2 HDMI displayport gbe black-null
Product image: Gigabyte h810m k micro-atx motherboard lga 1851 intel h810 ddr5 pcie 4.0 x16 m.2 HDMI displayport gbe black-null
Product image: Gigabyte h810m k micro-atx motherboard lga 1851 intel h810 ddr5 pcie 4.0 x16 m.2 HDMI displayport gbe black-null
GIGABYTE
🔥Πωλείται γρήγορα!

Gigabyte h810m k micro-atx motherboard lga 1851 intel h810 ddr5 pcie 4.0 x16 m.2 HDMI displayport gbe black

από € 114.38 σε - 10% - 10% € 102.95
ή
Πλήρωσε σε 3, 6 ή 9 άτοκες δόσεις με 0 χρεώσεις υπηρεσίας χρησιμοποιώντας το Fleksy image
Επιλογή Χρώμα: Black
Σε απόθεμα
–+
–+
204
Points earned
Μπορείτε να κερδίζετε βαθμούς Ανταμοιβή κάθε φορά που πραγματοποιείτε μια πληρωμή με τις κάρτες της Τράπεζας Κύπρου.
Ο αριθμός των βαθμών Ανταμοιβή και το αντίστοιχο ποσό χρημάτων που εμφανίζονται είναι ενδεικτικά και μπορεί να διαφέρουν κατά καιρούς. Θέλετε να μάθετε περισσότερα; Ελέγξτε τις Συχνές Ερωτήσεις μας εδώ.
Εάν είστε δικαιούχο μέλος του σχεδίου επιβράβευσης Pronomia της Τράπεζας Κύπρου, θα λαμβάνετε επιπλέον βαθμούς Ανταμοιβή ανάλογα με την βαθμίδα σας.
Από: Singular Computers Systems LTD
Περισσότερα από αυτό το κατάστημα
Επιλογές μεταφορικών
Σημεία / Θυρίδες παραλαβής
Εκτ. παράδοση: 26 Ιουν - 29 Ιουν
Δωρεάν
Παράδοση στην πόρτα σου
Δωρεάν αποστολή για παραγγελίες άνω των € 85.00 από το Singular Computers Systems LTD
Εκτ. παράδοση: 29 Ιουν - 01 Ιουλ
Δωρεάν

Περιγραφή

Αριθμός προϊόντος: a2b3574d-2ea5-471a-b450-8e434bfc99a0
Gigabyte H810M K — Essential Micro-ATX for Intel Core Ultra LGA 1851 · Intel H8102× DDR5 up to 128GBPCIe 4.0 x16 + M.2HDMI · DisplayPort · GbE The Gigabyte H810M K is an entry-level micro-ATX motherboard built on the Intel H810 chipset and the LGA 1851 socket, supporting Intel Core Ultra Series 2 (Arrow Lake) desktop processors. Sold under Gigabyte part number H810M K (EAN 4719331868697), it offers DDR5 memory, a PCIe 4.0 x16 graphics slot, a PCIe 4.0 M.2 slot and four SATA ports — a dependable

Χαρακτηριστικά

Χαρακτηριστικά Μητρικής Κάρτας

  • Θύρα Επεξεργαστή: Socket 1851

Λεπτομέρειες

Gigabyte H810M K — Essential Micro-ATX forIntel Core Ultra

LGA 1851 · Intel H8102× DDR5 up to 128GBPCIe 4.0 x16 + M.2HDMI · DisplayPort · GbE

The Gigabyte H810M K is an entry-level micro-ATX motherboard built on the Intel H810 chipset and the LGA 1851 socket, supportingIntel Core Ultra Series 2 (Arrow Lake) desktop processors. Sold under Gigabyte part number H810M K (EAN 4719331868697), it offers DDR5 memory, a PCIe 4.0 x16 graphics slot, a PCIe 4.0 M.2 slot and four SATA ports — a dependable, budget-friendly base for home, office and everyday computing. Typically in stock with fast delivery across Cyprus.

Compatibility — read before buying
This is an LGA 1851 board supporting onlyIntel Core Ultra Series 2 (Arrow Lake) desktop CPUs — not LGA 1700 (12th/13th/14th Gen). It uses DDR5 memory only (no DDR4), with two DIMM slots (max 128GB), and runs graphics/storage at PCIe 4.0 (the H810 chipset does not provide PCIe 5.0).

Best For

✓Home and officeIntel Core Ultra builds
✓Budget-conscious everyday computing
✓Compact Micro-ATX systems
✓Builds using integrated graphics (HDMI/DP)
✓Single NVMe + four SATA storage
✓Pairing with Core Ultra 5 / entry CPUs

Key Features


Intel Core Ultra ready
The LGA 1851 socket and Intel H810 chipset supportIntel Core Ultra Series 2 (Arrow Lake) processors for modern, efficient performance on a budget.

DDR5 memory
Two DDR5 DIMM slots support up to 128GB of dual-channel memory at 6400/5600 MT/s for smooth multitasking.

M.2 + 4× SATA storage
A PCIe 4.0 x4 M.2 slot (2280) for a fast NVMe boot drive, plus four SATA 6GB/s ports for additional storage.

Dual 4K display ouTPUt
Onboard HDMI (up to 4096×2160@60Hz) and DisplayPort (up to 4K@60Hz) let you run integrated graphics straight out of the box.

Technical Specifications

Identification
Part Number H810M K
EAN / GTIN 4719331868697
Brand Gigabyte
Platform
Chipset Intel H810
Socket LGA 1851
CPU Support Intel Core Ultra Processors (Series 2) — Arrow Lake desktop
Form Factor Micro-ATX
Memory
Slots 2× DDR5 DIMM (Dual-Channel)
Max Capacity 128GB (64GB per DIMM)
Speed DDR5 6400 / 5600 MT/s
Expansion & Storage
PCIe Slot 1× PCIe 4.0 x16
M.2 1× M.2 PCIe 4.0 x4 (2280)
SATA 4× SATA 6GB/s
Connectivity & I/O
LAN GbE LAN (RJ-45)
Display Out 1× HDMI (4K@60) + 1× DisplayPort (4K@60)
Rear USB 2× USB 3.2 Gen 1 + 4× USB 2.0
Audio HD Audio
Other
Colour Black
Operating System Windows 11 64-bit

Frequently Asked Questions

Which CPUs work with the Gigabyte H810M K?
It supportsIntel Core Ultra Series 2 (Arrow Lake) desktop processors on the LGA 1851 socket. Older LGA 1700 chips (12th/13th/14th Gen Core) are not compatible.
Does it support PCIe 5.0?
No. The Intel H810 chipset provides PCIe 4.0 for both the x16 graphics slot and the M.2 slot. For PCIe 5.0 graphics and storage, step up to a B860 board.
How much memory can I install?
Two DDR5 DIMM slots support up to 128GB of dual-channel memory at 6400/5600 MT/s. DDR4 is not supported.
How is the H810M K different from the H810M S2H?
Both are entry H810 LGA 1851 boards; the H810M K is the most basic model with HDMI and DisplayPort ouTPUts, while the S2H additionally includes a D-Sub (VGA) ouTPUt.
Singular Expert Insight
The H810M K is the simplest, lowest-cost route onto theIntel Core Ultra (LGA 1851) platform — it sticks to PCIe 4.0, a single M.2 and GbE LAN to hit a low price for home and office systems. If you need a legacy VGA ouTPUt, the H810M S2H adds D-Sub; for PCIe 5.0 graphics, a second M.2 and faster 2.5GBE, the Gigabyte B860M D3HP is the upgrade. Pair it with a reliable internal NVMe SSD for a snappy everyday build.

Buyer's Guide

Buy it if
You want the most affordable, reliable micro-ATX board for a home or officeIntel Core Ultra build with DDR5 and dual 4K display ouTPUt.
Skip it if
You want PCIe 5.0, dual M.2, 2.5GBE, Wi-Fi or a VGA ouTPUt — choose a B860 board or the H810M S2H.
Also consider
The Gigabyte H810M S2H (adds VGA) or B860M D3HP (PCIe 5.0 and faster networking).
