Gigabyte ud1000gm pg5 v2 1000w atx 3.1 psu 80+ gold cybenetics platinum fully modular pcie 5.1 12v-2x6 black

Name: Gigabyte ud1000gm pg5 v2 1000w atx 3.1 psu 80+ gold cybenetics platinum fully modular pcie 5.1 12v-2x6 black
Brand: GIGABYTE
SKU: d84d1a2e-53fa-410a-96ee-89b186a328a8
Price: 173.53 EUR
Availability: InStock

Product image: Gigabyte ud1000gm pg5 v2 1000w atx 3.1 psu 80+ gold cybenetics platinum fully modular pcie 5.1 12v-2x6 black-null

GIGABYTE

Gigabyte ud1000gm pg5 v2 1000w atx 3.1 psu 80+ gold cybenetics platinum fully modular pcie 5.1 12v-2x6 black

€ 192.80 - 10% € 173.53

Πλήρωσε σε 3, 6 ή 9 άτοκες δόσεις με 0 χρεώσεις υπηρεσίας χρησιμοποιώντας το

Επιλογή Χρώμα: Black

Σε απόθεμα

Ποσότητα

–+

Από: Singular Computers Systems LTD

Περισσότερα από αυτό το κατάστημα

Σημεία / Θυρίδες παραλαβής

Εκτ. παράδοση: 26 Ιουν - 29 Ιουν

Δωρεάν

Παράδοση στην πόρτα σου

Δωρεάν αποστολή για παραγγελίες άνω των € 85.00 από το Singular Computers Systems LTD

Εκτ. παράδοση: 29 Ιουν - 01 Ιουλ

Δωρεάν

Περιγραφή

Αριθμός προϊόντος: d84d1a2e-53fa-410a-96ee-89b186a328a8

Gigabyte UD1000GM PG5 V2 1000W Power Supply 1000W80+ GoldATX 3.1 / PCIe 5.1Fully Modular The Gigabyte UD1000GM PG5 V2 is a 1000 watt fully modular ATX power supply built for high-end gaming PCs running a modern graphics card and a many-core CPU. Supplied under part number GP-UD1000GM PG5 V2, this revised V2 model is fully compliant with the ATX 3.1 and PCIe 5.1 standards and ships with a native 16-pin 12V-2x6 cable that delivers up to 600 W to the latest GPUs directly, while 80 PLUS Gold effici

Λεπτομέρειες

Gigabyte UD1000GM PG5 V2 1000W Power Supply

1000W80+ GoldATX 3.1 / PCIe 5.1Fully Modular

The Gigabyte UD1000GM PG5 V2 is a 1000 watt fully modular ATX power supply built for high-end gaming PCs running a modern graphics card and a many-core CPU. Supplied under part number GP-UD1000GM PG5 V2, this revised V2 model is fully compliant with the ATX 3.1 and PCIe 5.1 standards and ships with a native 16-pin 12V-2x6 cable that delivers up to 600 W to the latest GPUs directly, while 80 PLUS Gold efficiency and a Cybenetics Platinum rating keep it cool and economical. Typically in stock with fast delivery across Cyprus.

Before you buy — fit & compatibility

This is a standard ATX-format, fully modular unit with a compact 140 mm depth that fits most cases. The native 12V-2x6 cable powers modern ATX 3.1 / PCIe 5.1 graphics cards directly; older cards use the included 8-pin PCIe cables. This is the updated V2 revision with the current 12V-2x6 connector.

Best For

✓High-end gaming PCs with flagship GPUs

✓Content-creation and rendering workstations

✓PCIe 5.1 / 12V-2x6 graphics card builds

✓Overclocked CPU + GPU systems

✓Future-proof ATX 3.1 upgrades

✓Compact cases (140 mm depth)

Key Features

ATX 3.1 · PCIe 5.1 · 12V-2x6

Ships with a native 16-pin 12V-2x6 cable that delivers up to 600 W to modern PCIe 5.1 graphics cards directly, and handles up to 3× GPU power excursions.

80+ Gold · Cybenetics Platinum

Certified 80 PLUS Gold with a higher Cybenetics Platinum efficiency rating, around 90% efficient at 50% load, so it wastes less energy as heat.

Fully Modular · Japanese Caps

Attach only the cables you need for a clean build, backed by 100% Japanese capacitors and a single +12V rail design for stable power delivery.

120mm HYB Fan · V2 Revision

A 120 mm smart hydraulic-bearing fan keeps the unit cool and quiet, and this updated V2 model uses the current 12V-2x6 connector design.

Technical Specifications

Identification
Part Number	GP-UD1000GM PG5 V2
EAN / GTIN	4719331556112
MPN	UD1000GM PG5 V2
Power
Maximum OuTPUt	1000 W
Form Factor	ATX (ATX12V V3.1)
Rail Design	Single +12V rail
PFC	Active PFC
Efficiency	80 PLUS Gold · Cybenetics Platinum
Design
Modularity	Fully modular
Main GPU Connector	Native 16-pin 12V-2x6 — PCIe 5.1, up to 600 W to one card
Capacitors	100% Japanese
Power Excursion	Up to 3× GPU power excursion
Cooling
Fan	120 mm smart hydraulic bearing (HYB)
Protection
Safety	OVP / OPP / SCP / UVP / OCP / OTP / NLO / SIP
Physical
Depth	140 mm
Colour	Black
Warranty
Manufacturer Warranty	10-year limited

Frequently Asked Questions

Does the UD1000GM PG5 V2 work with the latest GeForce RTX cards?

Yes. It includes a native 16-pin 12V-2x6 cable — the PCIe 5.1 power connector used by the newest high-end graphics cards — delivering up to 600 W directly without adapters.

What is different about the V2 version?

The V2 is the updated revision of the UD1000GM PG5, built to the ATX 3.1 / PCIe 5.1 standard with the current 12V-2x6 connector design, while keeping the same 1000 W ouTPUt, 80+ Gold efficiency and fully modular layout.

Is 1000W enough for my build?

For the vast majority of single-GPU systems, yes — 1000 W comfortably powers a high-end graphics card alongside a many-core CPU, with headroom for storage, cooling and moderate overclocking.

Is this power supply fully modular?

Yes. Every cable detaches, including the 24-pin, so you only install the cables your system needs for cleaner cable management and better airflow.

Singular Expert Insight

This is the version of the UD1000GM PG5 to buy: the V2 revision is built around the current 12V-2x6 connector and the ATX 3.1 / PCIe 5.1 standards, with a compact 140 mm body, Japanese capacitors and a 10-year warranty. At 1000 W it is well matched to a high-end single-GPU build; if you run a flagship 500 W-plus card or plan dual GPUs, look at a 1200 W-plus unit instead, and if you want even higher efficiency a Platinum-rated supply is the upgrade. Compare wattages across our PC power supplies, or pair it with a new graphics card for a complete high-end build.

Buyer’s Guide

Buy it if

You run a high-end single GPU, want ATX 3.1 with a native 12V-2x6 cable, Japanese capacitors and a 10-year warranty in a compact 140 mm body.

Skip it if

You run a flagship 500 W-plus GPU or plan dual cards — choose a 1200 W-plus unit for more headroom.

Also consider

A 1200 W ATX 3.1 unit for flagship GPUs, or a Platinum-rated 1000 W supply if maximum efficiency matters most.
