Qnap ts-864eu-8g 8-bay 2u short-depth rackmount nas intel celeron n5095 8GB ddr4 dual 2.5GBe HDMI diskless

Name: Qnap ts-864eu-8g 8-bay 2u short-depth rackmount nas intel celeron n5095 8GB ddr4 dual 2.5GBe HDMI diskless
Brand: QNAP
SKU: 043604bc-779d-4c9d-9978-c8d6be6e2fc9
Price: 2592.21 EUR
Availability: InStock

QNAP

Qnap ts-864eu-8g 8-bay 2u short-depth rackmount nas intel celeron n5095 8GB ddr4 dual 2.5GBe HDMI diskless

€ 2,592.21

Aπομένουν μόνο 1!

Πλήρωσε σε 3, 6 ή 9 άτοκες δόσεις με 0 χρεώσεις υπηρεσίας χρησιμοποιώντας το

Επιλογή Χρώμα: Black

Χαμηλό απόθεμα

Τύπος Δίσκου

Ποσότητα

–+

Από: Singular Computers Systems LTD

Περισσότερα από αυτό το κατάστημα

Παράδοση στην πόρτα σου

Δωρεάν αποστολή για παραγγελίες άνω των € 85.00 από το Singular Computers Systems LTD

Εκτ. παράδοση: 03 Αυγ - 05 Αυγ

Δωρεάν

Περιγραφή

Αριθμός προϊόντος: 043604bc-779d-4c9d-9978-c8d6be6e2fc9

QNAP TS-864eU-8G — 8-Bay 2U Short-Depth Rackmount NAS Short-Depth 297mm ChassisIntel Celeron N50958GB DDR4Dual 2.5GBE + HDMI The QNAP TS-864eU-8G is a diskless 8-bay 2U short-depth rackmount NAS powered by a quad-core Intel Celeron N5095 processor with 8GB of DDR4 memory, designed for businesses and media environments that need eight-bay capacity in a shallow rack or wall cabinet. Supplied under model TS-864eU-8G (EAN 4711103082195), it houses eight 3.5"/2.5" SATA drives, adds dual 2.5GBE with

Χαρακτηριστικά

Γενικά Χαρακτηριστικά Σκληρού Δίσκου

Τύπος Δίσκου: Ethernet | SATA | iSCSI | USB3.1

Λεπτομέρειες

QNAP TS-864eU-8G — 8-Bay 2U Short-Depth Rackmount NAS

Short-Depth 297mm ChassisIntel Celeron N50958GB DDR4Dual 2.5GBE + HDMI

The QNAP TS-864eU-8G is a diskless 8-bay 2U short-depth rackmount NAS powered by a quad-core Intel Celeron N5095 processor with 8GB of DDR4 memory, designed for businesses and media environments that need eight-bay capacity in a shallow rack or wall cabinet. Supplied under model TS-864eU-8G (EAN 4711103082195), it houses eight 3.5"/2.5" SATA drives, adds dual 2.5GBE with port trunking up to 5GBps, an HDMI ouTPUt and a PCIe Gen3 slot for 10GBE or M.2 expansion. Typically in stock with fast delivery across Cyprus.

Before you buy — ships diskless

The TS-864eU is supplied as an enclosure only; SATA drives are sold separately (choose NAS-rated drives), and the rail kit is optional. There is no onboard M.2 — NVMe SSD or 10GBE is added via the single PCIe Gen3 x2 slot. This model uses one 300W power supply; for redundant power choose the TS-864eU-RP instead.

Best For

✓Shallow racks, media and AV cabinets

✓Eight-bay business file serving

✓Port-trunked 2.5GBE multi-user access

✓Virtualization storage over iSCSI or NFS

✓QuTS hero ZFS with data integrity

✓4K media ouTPUt over HDMI

Key Features

Short-Depth 2U Design

At just 297mm deep, the TS-864eU fits shallow racks, wall-mount cabinets and AV environments where a full-depth rackmount will not go.

Intel Celeron N5095 Quad-Core

A 2.0GHz (burst 2.9GHz) x86 processor with AES-NI, paired with 8GB DDR4 (expandable to 16GB), runs both QTS and ZFS-based QuTS hero.

Dual 2.5GBE Networking

Two 2.5GBE ports support port trunking up to 5GBps, and the PCIe Gen3 slot accepts a 10GBE card or M.2 SSD adapter for more speed.

HDMI and Multimedia

An HDMI 1.4b ouTPUt enables local playback and HD Station, while the eight bays provide high capacity for backups, surveillance and shared storage.

Technical Specifications

Identification
Model	TS-864eU-8G
EAN / GTIN	4711103082195
MPN	TS-864eU-8G
Processor & Memory
CPU	Intel Celeron N5095 — quad-core, 2.0GHz burst to 2.9GHz
Memory	8GB SO-DIMM DDR4 (1x 8GB) — expandable to 16GB (2x 8GB)
Storage
Drive Bays	8x 3.5" / 2.5" SATA III, hot-swap
M.2 Slot	Optional via PCIe adapter (no onboard M.2)
RAID Levels	Single, JBOD, RAID 0/1/5/6/10/50/60
Connectivity
Ethernet	2x 2.5GBE RJ45 — port trunking to 5GBps
USB	2x USB 3.2 Gen2 (10GBps) Type-A + 2x USB 2.0
HDMI	1x HDMI 1.4b
PCIe	1x PCIe Gen3 x2 — 10GBE or M.2 adapter
Physical & Power
Form Factor	2U short-depth rackmount — depth 297.4mm
Dimensions	88.6 (H) x 432 (W) x 297.4 (D) mm
Weight	7.78 kg
Power Supply	300W single (100-240V) — RP model adds redundant PSU
Cooling	2x 80mm fans
Software & Warranty
Operating System	QTS / QuTS hero (ZFS)
Condition	New
Warranty	3 years

Frequently Asked Questions

Does the TS-864eU come with drives or rails?

No. It ships diskless as an 8-bay enclosure and the rail kit is optional. Add NAS-rated SATA drives to build your array, and check that your rack accepts the short 297mm depth.

Can I add 10GBE or M.2 SSD cache?

Yes, via the PCIe Gen3 x2 slot. There is no onboard M.2, so NVMe SSD caching or a 10GBE upgrade uses a QNAP PCIe adapter card in that slot.

What is the difference between the TS-864eU and TS-864eU-RP?

Both share the same 8-bay short-depth hardware and Celeron N5095 CPU. The TS-864eU-RP adds a redundant (dual) power supply for higher uptime, while the TS-864eU uses a single 300W PSU.

Does it run QuTS hero with ZFS?

Yes. As an x86 model the TS-864eU supports both the standard QTS and the ZFS-based QuTS hero operating system, which adds data integrity, deduplication and advanced snapshots.

Singular Expert Insight

The TS-864eU is the practical choice when rack depth is tight: its 297mm short-depth chassis fits cabinets that full-depth 8-bay units cannot, while the x86 Celeron N5095 unlocks QuTS hero ZFS and HDMI ouTPUt. Choose the TS-864eU-RP if you need redundant power, or the 4-bay TS-464eU for a smaller footprint. Fill the bays with reliable NAS-rated hard drives, and compare it with other rack and desktop models in the full range of NAS and RAID storage appliances.

Buyer’s Guide

Buy it if

You need eight bays in a short-depth 2U rack with dual 2.5GBE, HDMI and a PCIe slot for 10GBE, plus QuTS hero ZFS support.

Skip it if

You need redundant power (choose the TS-864eU-RP), built-in 10GBE, or onboard M.2 slots without using the single PCIe slot.

Also consider

The TS-864eU-RP for redundant PSUs, or the 4-bay TS-464eU if you need fewer bays in the same short-depth family.
