TP-Link Omada EAP787 Wi-Fi 7 Access Point
Enterprise BE12000 tri-band Wi-Fi 7 with a 10G PoE++ uplink and Omada SDN management for high-density sites.
Wi-Fi 7 · BE12000Tri-Band 8-Stream10G PoE++ UplinkCeiling MountOmada SDN
The TP-Link Omada EAP787 is a top-tier Wi-Fi 7 ceiling access point delivering BE12000 tri-band performance across 2.4 GHz, 5 GHz and 6 GHz with eight spatial streams. Wi-Fi 7 technologies — 320 MHz channels, 4K-QAM and Multi-Link Operation (MLO) — combine bands for dramatically higher throughput and lower latency. A 10 Gigabit uplink with PoE++ (802.3bt) removes the wired bottleneck of older APs, so a single unit can serve dense, high-bandwidth environments. It is centrally managed by Omada SDN — cloud, controller or standalone — for zero-touch provisioning and unified control across the whole network.
Deployment note: The 10G uplink needs a PoE++ (802.3bt) source — use an Omada 10G PoE++ switch or an 802.3bt injector. The 6 GHz band and full Wi-Fi 7 speeds require Wi-Fi 6E/7 client devices.
Best For
✓High-density offices, campuses and conference spaces
✓Venues and public areas with heavy, high-bandwidth demand
✓Networks with multi-gig internet that need a 10G AP uplink
✓Wi-Fi 6E/7 client fleets that can use the 6 GHz band
✓Omada SDN deployments wanting unified, zero-touch management
✓Future-proofing an access layer for Wi-Fi 7
Key Features
BE12000 Tri-Band Wi-Fi 7
Three concurrent radios with 320 MHz channels, 4K-QAM and MLO deliver far higher throughput and lower latency than Wi-Fi 6.
8 Spatial Streams
An eight-stream design maximises capacity for crowded, high-bandwidth environments.
10G PoE++ Uplink
A 10 Gigabit uplink with 802.3bt power eliminates the 1GBE bottleneck and simplifies cabling to one run.
Omada SDN Management
Cloud, controller or standalone management with zero-touch provisioning and unified control across all Omada devices.
Technical Specifications
| Identification |
| Part Number |
EAP787 |
| EAN / GTIN |
1210002600569 |
| MPN |
EAP787 |
| Brand |
TP-Link Omada |
| Wireless |
| Wi-Fi Standard |
802.11be (Wi-Fi 7), triple-radio |
| Rated Speed |
BE12000 (EU), 8-stream — 2.4 / 5 / 6 GHz |
| Wi-Fi 7 Features |
320 MHz channels, 4K-QAM, Multi-Link Operation (MLO) |
| Connectivity |
| Uplink Port |
1× 10 Gigabit (RJ-45) |
| Power over Ethernet |
PoE++ (IEEE 802.3bt) |
| Management |
Omada SDN (cloud / controller / standalone) |
| Physical |
| Mounting |
Ceiling (indoor) |
| Colour |
White |
| General |
| Warranty |
1-Year Warranty (Singular) |
Frequently Asked Questions
What makes the EAP787 a high-end Wi-Fi 7 AP?
It combines BE12000 tri-band, 8-stream radios with a 10G PoE++ uplink, so both the wireless and wired sides are built for dense, high-bandwidth use.
What power does it need?
PoE++ (802.3bt). Use an Omada 10G PoE++ switch or an 802.3bt injector — standard PoE/PoE+ will not fully power the 10G model.
Do I need Wi-Fi 7 devices to benefit?
You gain capacity and the 10G uplink with any clients, but the 6 GHz band and full Wi-Fi 7 speeds require Wi-Fi 6E or Wi-Fi 7 devices.
How is it managed?
Through Omada SDN — cloud, hardware/software controller or standalone — with zero-touch provisioning and unified management.
Expert Insight
Wi-Fi 7 only shines when the wired side keeps up. Browse our full range of access points to plan coverage, and pair the EAP787 with a 10G PoE++ switch from our switches & bridges range to unlock its full throughput.
Buyer's Guide
Buy it if…
You need flagship Wi-Fi 7 with a 10G uplink for high-density sites and run (or plan) multi-gig Omada switching.
Skip it if…
Your switch only offers 1GBE PoE/PoE+ or you have light client counts — a 2.5G Wi-Fi 6/7 EAP is more cost-effective.
Also consider…
A 2.5G Omada Wi-Fi 7 EAP for standard deployments, or an outdoor EAP where weatherproofing is required.
